Chicago Pneumatic CP9104Q Micro Pencil Die Grinder 1/8" 3mm Collet 60000 rpm
Model : #CP9104Q
Share This Item:
Chicago Pneumatic CP9104Q Micro Pencil Grinder
This quiet and lightweight, easy to handle micro pencil grinder is ideal for limited space applications.
Features
- 3 mm and 1/8" Collets Included
- Very Low Noise Level: Only 71 dB(A)
- Includes Silencer Hose
- High Free Speed: 60,000 rpm
Specifications
Part number | 6151959104 | |
Length | 133 mm | 5.2" |
Net weight | 0.2 kg | 1/2 lb |
Average air consumption | 1.6 l/s | 3.5 cfm |
Average air consumption | 96 l/mn | 3.5 cfm |
Actual air consumption | 3.2 l/s | 7 cfm |
Actual air consumption | NC 7 | |
Free speed air consumption | 3.3 l/s | 7 cfm |
Air inlet thread size | 1/4" | |
Min. hose size | 10 mm | 3/8" |
Sound pressure | 71 db(A) | |
Sound Power | 82 db(A) | |
Vibration ISO | ISO-28927-12 | |
Vibration | <2.5 m/s² | |
Free speed | 60000 rpm | |
Power | 40 W | 0.05 hp |
Rear exhaust | Rear exhaust | |
Collet size | 3 mm | 1/8" |
(CP9104Q)
Barcode # | 15451539030 |
Brand | Chicago Pneumatic |
Shipping Cubic | 0.001330000m3 |
