Chicago Pneumatic CP9104Q Micro Pencil Grinder

This quiet and lightweight, easy to handle micro pencil grinder is ideal for limited space applications.


Features

  • 3 mm and 1/8" Collets Included
  • Very Low Noise Level: Only 71 dB(A)
  • Includes Silencer Hose
  • High Free Speed: 60,000 rpm


Specifications

Part number 6151959104
Length 133 mm 5.2"
Net weight 0.2 kg 1/2 lb
Average air consumption 1.6 l/s 3.5 cfm
Average air consumption 96 l/mn 3.5 cfm
Actual air consumption 3.2 l/s 7 cfm
Actual air consumption NC 7
Free speed air consumption 3.3 l/s 7 cfm
Air inlet thread size 1/4"
Min. hose size 10 mm 3/8"
Sound pressure 71 db(A)
Sound Power 82 db(A)
Vibration ISO ISO-28927-12
Vibration <2.5 m/s²
Free speed 60000 rpm
Power 40 W 0.05 hp
Rear exhaust Rear exhaust
Collet size 3 mm 1/8"



(CP9104Q)

Barcode # 15451539030
Brand Chicago Pneumatic
Shipping Cubic 0.001330000m3
